Long Span Steel Framed Workshops Heavy Duty Load Customizable Size Industrial Use

Brand Name : HCGG

Model Number : SSWK001

Certification : CE/ISO 9001/ISO 3834/ISO 14001/ISO 45001

Place of Origin : Henan,China

MOQ : 50 square meters

Price : USD25-100 Square Meter/Negotiable

Payment Terms : L/C,T/T,Western Union,Alibaba.pay

Supply Ability : 50000 Tons/year

Delivery Time : 20-50days

Main Structurel Material : Q355B/ASTM A572 Gr.50/EN S355/JIS SM490

Secondary StructurelMaterial : Q235B / ASTM A36/ EN S235JR / JIS SS400

Other Material : Q460 / ASTM A572 Gr.65 /EN S460 / JIS SM570

Customization : Style,size,Color,Material

Project Solution Capability : CAD graphic design, 3D Tekla modeling design, total solution for projects,One-stop steel structure solution,Project-based supply

After-sale Service : Online Technical Support, Onsite Installation,Onsite Training,Onsite Inspection,Installation Drawings Support

Column and Beam : Welded H-section/Hot-rolled H-beam/Box column

Purlin : C.Z Shape Steel Channel

Roof and Wall panel : EPS/Rock wool/PU / PIR sandwich panel,Corrugated/Trapezoidal steel sheet/Customized

Window : Aluminum alloy / PVC /Industrial louver window

Door : Sliding/Rolling shutter/Hinged steel/Customized steel door

Surface treatment : Hot-dip galvanized Zinc-rich primer + top coat Anti-corrosion coating

Service Life : 20-50 Years

Life Span : More Than 50 Years

Secondary Structurel Material : Q235B / ASTM A36/ EN S235JR / JIS SS400

Roof And Wall Panel : EPS/Rock Wool/PU / PIR Sandwich Panel Corrugated/Trapezoidal Steel Sheet/Customized

Contact Now

Professional Steel Structure Workshop
Long-span steel workshops with heavy-duty load capacity for industrial applications.
Product Overview
Steel structure workshops are modern industrial buildings that use steel components as the main load-bearing frame. These prefabricated industrial buildings utilize steel beams, columns, and trusses as the primary support system. Constructed from high-quality steel, they offer lightweight durability, exceptional load-bearing capacity, and extended service life. The modular design enables rapid assembly, high construction efficiency, and cost-effectiveness. Widely used in manufacturing, processing, assembly, and various industrial production facilities, these structures can be flexibly configured with doors, windows, cranes, insulation layers, and other components, making them an ideal choice for factories, production lines, and industrial workshops worldwide.
Long Span Steel Framed Workshops Heavy Duty Load Customizable Size Industrial Use
Technical Specifications
Component Specification
Main Steel Frame
Column Q235, Q355 Welded H Section Steel
Beam Q235, Q355 Welded H Section Steel
Secondary Frame
Purlin Q235 C and Z Purlin
Knee Brace Q235 Angle Steel
Tie Rod Q235 Circular Steel Pipe
Brace Q235 Round Bar
Vertical & Horizontal Support Q235 Angle Steel, Round Bar or Steel Pipe
Cladding System
Roof Panel EPS Sandwich Panel / Glass Fiber Sandwich Panel / Rock Wool Sandwich Panel / PU Sandwich Panel / Steel Sheet
Wall Panel EPS Sandwich Panel / Glass Fiber Sandwich Panel / Rock Wool Sandwich Panel / PU Sandwich Panel / Steel Sheet
Accessories
Window Aluminium Alloy Window / PVC Window
Door Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door
Rainspout PVC
Key Advantages
  • High-strength main steel structure with excellent seismic and wind resistance for safer operation
  • High-precision factory prefabrication with fast on-site installation, significantly reducing construction timelines
  • Large-span column-free design providing high space utilization and flexible layout options
  • Advanced anti-corrosion and anti-rust technology ensuring long service life with minimal maintenance costs
  • Fully customizable size, height, doors, windows, and crane configurations to meet specific requirements
Long Span Steel Framed Workshops Heavy Duty Load Customizable Size Industrial Use Long Span Steel Framed Workshops Heavy Duty Load Customizable Size Industrial Use Long Span Steel Framed Workshops Heavy Duty Load Customizable Size Industrial Use
Frequently Asked Questions
What is the service life of your steel structure buildings?
50-100 years, depending on material grade, surface treatment, and local environmental conditions.
Can the size be customized?
Yes, span (6m-30m/customized), eave height (3m-20m/customized), and length can be fully customized to your specifications.
What materials are used for the steel structure?
Primarily Q235B, Q355B, A36, S355JR steel grades with painting or hot-dip galvanizing surface treatment for enhanced durability.
How long is the installation cycle?
Approximately 50% shorter than traditional buildings; small to medium projects typically take 1-4 weeks for completion.
Do you provide installation service?
Yes, we provide professional installation teams and comprehensive on-site guidance services.
